A210L - Atrust

A210L

Atrust A210L is a Linux-based All-in-One thin client especially designed for a client / server computing environment. Developed by Atrust, the ACS ( Atrust Client Setup ) software is also built in to help effective management of A210L. With the support of Citrix® ICA / HDX™, Microsoft® RDP™ with RemoteFX™ and VMware® Horizon View™, A210L can be used to create virtual and session-based desktop experiences from many remote desktop capable operating systems. A210L offers a rich computing experience where applications look, feel, and behave as local devices, including high-definition multimedia content.

Software

Certifications

Full HD

All in one. 23.6” diagonal LED backlight display & full HD resolution for a small desktop footprint.

Plug and play

Simply connect keyboard, mouse to A210L, after Atrust Linux software setup you can start to play without any installation process.

Quiet design

With its fanless design, it creates a simple and noiseless workplace environment.

Compact design

The compact A210L can fit anywhere and uses less desktop space.

1.Power Button

* Press to :
a) Turn on the system.
b) Resume from the suspend mode.
* Long press to power off the system.

2.Microphone Port

It connects to a microphone.

3.Headphone Port

It connects to a headphone or a speaker system.

4.USB 2.0 Port x 4

It connects to USB devices.

5.Kensington Lock Slot

Attach the A200A to a permanent object with the Kensington slot and a security cable.

6.Kensington Lock Slot

Attach the A200A to a permanent object with the Kensington slot and a security cable.

7.LAN Port

It connects to a host server through a LAN switch.

8.USB 3.2 Gen 1 Port x 2

It connects to USB device.

9.DisplayPort

It connects to a monitor.

10.DC IN

It connects to an AC adapter.

Processor

Intel® Braswell Quad Core X5-E8000 1.04 G ( Burst to 2.0 G )

System memory

4 GB

Storage

8 GB

LCD Type / Resolution

23.6” LED Backlight / Up to 1920 x 1080

I/O ports

1 x DisplayPort
2 x USB 3.2 Gen 1
4 x USB 2.0
1 x Audio out
1 x Microphone port
1 x RJ-45
1 x DC IN
2 x Kensington lock slot

Ethernet

10 M / 100 M / 1 G

Dimensions

( W ) 569.6 x ( D ) 183.5 x ( H ) 412.3 mm

Weight

4.65 kg ( approximate )

Cooling

Fanless

Operating noise

No noise

Operating temperature

0℃ ~ 35℃

Non-operating temperature

-20℃ ~ 60℃

Operating humidity ( Rh )

10% ~ 90% ( non-condensing )

Non-operating humidity ( Rh )

5% ~ 95% ( non-condensing )

Operating voltage range

100 ~ 240 VAC

Rated line frequency

50 ~ 60 Hz

AC Adapter

19V, 65W, 3.42A

Operating system

Atrust OS

Management

Atrust Device Manager ( ADM )
Atrust Client Setup ( ACS )

Protocols

Citrix® ICA / HDX™
Microsoft® RDP™ with RemoteFX™
VMware® Horizon View™ ( PCoIP / RDP / Blast )

Regulatory

CE / VCCI

Optional

WiFi : IEEE802.11 a / b / g / n / ac
Internal Speaker
Adjustable display stand
TPM ( Trusted Platform Module )

Atrust Device Manager

Atrust Device Manager is a powerful software for managing a large number of thin client devices in desktop virtualization infrastructure. It enables IT administrator to remotely deploy, manage, update clients, and assist users from a single computer. The administrator can manage and update clients simply and quickly in groups with a flexible and secure mechanism. Additionally, the IT administrator can remotely assist users in resolving problems or configuring local settings.

The key features of Atrust Device Manager

● helping the management of clients ( without a pre-installed operating system ) devices.
● pushing custom settings to a large number of clients.
● updating firmware and installing software packages for clients.
● rebooting, powering off, and waking clients simply through the local network.
● helping users to troubleshoot problems remotely.
● identifying clients and managing IT assets with detailed client information.
